EDAC EA1050B-240 AC ADAPTER 24VDC 2.5A POWER SUPPLY for Printer
EDAC EA1050B-240 AC ADAPTER 24V DC 2.5A 60W POWER SUPPLY for Printer
Condition: New - Working
Content : One Ac adapter only nothing else
Manufacturer: EDAC / Sunpower
Model: EA1050B-240
P/N.: 53120050B242
Model: EA1050B-240
P/N.: 53120050B242
Input: 100 - 240V ~ 50/60Hz. 1.8A
(: :) DC Output: 24V === 2.5A
Dimension: 12 x 6 x 3.4 cm approx.
Weight: 300g
More Info
Manufacturer Specification:
Input voltage 100 to 240Vac ±10%, full range
Input frequency 47 to 63Hz
Current 1.2A max. at 115Vac, 0.6A max. at 230Vac, full load
Inrush current 40A max. at 110Vac, 80A max. at 220Vac, cold start
Hold up time 8.3mS min. full load, nominal line
Input fuse fuse to line side of input
Line regulation dc voltage within tolerance when ac varies within the range specified
Dynamic load regulation ±5% excursion for 50-100% or 100-50% load change of dc at any frequency up to 1KHz (Duty 50%)
Leakage current Less than 0.75mA
Ripple and noise 250mV, 200mV on 20Vdc
Efficiency 78% typically, at full dc output load
Operating temperature 0 °C to 35 °C
Storage temperature -20 °C to 85 °C
Safety Approvals Designed to meet UL, cUL, TUV, BSMI, EK, PSE, NORDIC, 3C, CE & CB
EMC Complies with FCC Part 15 Class B & EN 55022 Class B
More Info
Manufacturer Specification:
Input voltage 100 to 240Vac ±10%, full range
Input frequency 47 to 63Hz
Current 1.2A max. at 115Vac, 0.6A max. at 230Vac, full load
Inrush current 40A max. at 110Vac, 80A max. at 220Vac, cold start
Hold up time 8.3mS min. full load, nominal line
Input fuse fuse to line side of input
Line regulation dc voltage within tolerance when ac varies within the range specified
Dynamic load regulation ±5% excursion for 50-100% or 100-50% load change of dc at any frequency up to 1KHz (Duty 50%)
Leakage current Less than 0.75mA
Ripple and noise 250mV, 200mV on 20Vdc
Efficiency 78% typically, at full dc output load
Operating temperature 0 °C to 35 °C
Storage temperature -20 °C to 85 °C
Safety Approvals Designed to meet UL, cUL, TUV, BSMI, EK, PSE, NORDIC, 3C, CE & CB
EMC Complies with FCC Part 15 Class B & EN 55022 Class B
Copyright © 2011 All rights reserved
Condition: 100% brand New
Warranty: Full 18 Months Warranty and 30 Days Money Back
Fast shipping!Free Power Cord Fit your country!
- Model: EDAC EA1050B-240 AC ADAPTER 24VD
- 6811 Units in Stock
