SINPRO SPU130-105  AC ADAPTER  12.5V dc 10.4A  New  130W 5Pin 13mm Din 100-240vac 130W Switching ITE Power Supply

 Input: 100-240VAC ~ 47-63Hz 3.2A
Made in Taiwan E183744 Looks New

Pin 1, 4: 12Vdc
Pin 2, 3, 5: Return Common
Shield/Shell: GND / Earth

SPU130 series
130W Desktop type switching power supplies for I.T.E.
The SPU130 series of AC/DC switching mode power supplies provide 130 Watts of continuous output power. All supplies are UL 94V-1 min compliant. All models meet FCC Part-15 class B and CISPR-22 class B emission Limits and are designed to comply with UL/c-UL(UL 60950-1:2nd Edition) , Intertek-GS(EN 60950-1:2nd Edition) and new CE requirements. All units are 100% burned in and tested.

Wide Operating Voltage 90 to 260 VAC, 47 to 63 Hz
 IEC-320-C14 Input Inlet
 Long Hold-Up Times (50mS)
 Single and Dual Output
 Option: Mounting Tab and Desk Top
 Include a cooling fan
 Active Power Factor Correction

Operating Temperature: 0 to 70 °C
Derate linearly from 100% load at 25 °C to 50% load at 70 °C
Storage Temperature: -40~85 °C
Operating Humidity : 0~95%
Storage Humidity: 0~95%
MTBF: 100,000 calculated hours

SPU130-105 11~13VDC 11.80~10.00A 130W
Total regulations 5%
Certificate: UL/CUL, ITS-GS, CE, CB, CCC, IRAM, PSE, FCC, RoHS

Weight: 596  grams
Dimension:  15.7 x 7.8 x  4.4  cm

To Use With: Medical equipment
